0536 Tule pressure plates
Assembled with a screw for fixation on concrete, stone, A.C.C, and wood.
Product Information
Assembled with a screw for fixation on concrete, stone, A.C.C, and wood.
Available Variants (42)
| Diameter (mm) | Length (mm) | A (mm) | B (mm) | C (mm) | D (mm) | Drill point |
|---|---|---|---|---|---|---|
| 4,8 | 40 | 40 | 35 | 40 | 80 | 1 |
| 4,8 | 50 | 50 | 35 | 50 | 80 | 1 |
| 4,8 | 60 | 60 | 35 | 60 | 80 | 1 |
| 4,8 | 70 | 70 | 65 | 40 | 80 | 1 |
| 4,8 | 80 | 80 | 65 | 50 | 80 | 1 |
| 4,8 | 90 | 90 | 65 | 60 | 80 | 1 |
| 4,8 | 100 | 100 | 95 | 40 | 80 | 1 |
| 4,8 | 110 | 110 | 95 | 50 | 80 | 1 |
| 4,8 | 120 | 120 | 95 | 60 | 80 | 1 |
| 4,8 | 130 | 130 | 125 | 40 | 80 | 1 |
| 4,8 | 140 | 140 | 125 | 50 | 80 | 1 |
| 4,8 | 150 | 150 | 125 | 60 | 80 | 1 |
| 4,8 | 160 | 160 | 155 | 40 | 80 | 1 |
| 4,8 | 170 | 170 | 155 | 50 | 80 | 1 |
| 4,8 | 180 | 180 | 155 | 60 | 80 | 1 |
| 4,8 | 190 | 190 | 185 | 40 | 80 | 1 |
| 4,8 | 200 | 200 | 185 | 50 | 80 | 1 |
| 4,8 | 210 | 210 | 185 | 60 | 80 | 1 |
| 4,8 | 220 | 220 | 215 | 40 | 80 | 1 |
| 4,8 | 230 | 230 | 215 | 40 | 80 | 1 |
| 4,8 | 240 | 240 | 215 | 60 | 80 | 1 |
| 4,8 | 40 | 40 | 35 | 40 | 80 | 1 |
| 4,8 | 50 | 50 | 35 | 50 | 80 | 1 |
| 4,8 | 60 | 60 | 35 | 60 | 80 | 1 |
| 4,8 | 70 | 70 | 65 | 40 | 80 | 1 |
| 4,8 | 80 | 80 | 65 | 50 | 80 | 1 |
| 4,8 | 90 | 90 | 65 | 60 | 80 | 1 |
| 4,8 | 100 | 100 | 95 | 40 | 80 | 1 |
| 4,8 | 110 | 110 | 95 | 50 | 80 | 1 |
| 4,8 | 120 | 120 | 95 | 60 | 80 | 1 |
| 4,8 | 130 | 130 | 125 | 40 | 80 | 1 |
| 4,8 | 140 | 140 | 125 | 50 | 80 | 1 |
| 4,8 | 150 | 150 | 125 | 60 | 80 | 1 |
| 4,8 | 160 | 160 | 155 | 40 | 80 | 1 |
| 4,8 | 170 | 170 | 155 | 50 | 80 | 1 |
| 4,8 | 180 | 180 | 155 | 60 | 80 | 1 |
| 4,8 | 190 | 190 | 185 | 40 | 80 | 1 |
| 4,8 | 200 | 200 | 185 | 50 | 80 | 1 |
| 4,8 | 210 | 210 | 185 | 60 | 80 | 1 |
| 4,8 | 220 | 220 | 215 | 40 | 80 | 1 |
| 4,8 | 230 | 230 | 215 | 40 | 80 | 1 |
| 4,8 | 240 | 240 | 215 | 60 | 80 | 1 |
